Three-stage arms for greater reach
• Original “Double S” column design
• Performance tested to 20,000 lift cycles
• Nationwide support
• ALI Gold Certified
Product Specifications
| Model | SPO12-TA |
|---|---|
| Capacity | 12,000 lbs. |
| Rise | 72 3/4” – 75 1/4” |
| Overall Height | 13′ 8″ |
| Base Required Ceiling Height | 14′ |
| Overall Width | 11′ 5 5/8″ |
| Drive-Thru Width | 8′ 6 3/8″ |
| Front Arm Min/Max | 27 1/2″-59″ |
| Rear Arm Min/Max | 27 1/2″-59″ |
| Min. Adapter Height | 4 3/4″ |
| Motor | 2 HP |
| Voltage | 208v-230v |
| Time of Full Rise/Decent | 60 secs./40 secs. |
| Min. Bay Size | 12’x26′ |
